Orbital Express Truss™ features over 40 professionally designed “off-the-shelf” kits for a variety of booth sizes and configurations. Each kit comes complete with all the parts, fixtures and fittings you need to create a successful exhibit, including (depending on the kit) low voltage spotlights and adjustable tabletops. A benefit to this versatile system is that it enables you to reconfigure kits in multiple ways and combinations using the same parts. Orbital Express Truss can also be easily customized!

*Includes couters

Features and Benefits:

• - 10’ x 20’ kit size
• - Custom appearance
• - Tooless assembly
• - Simple twist and lock design
• - 5 year warranty against manufacturer defects

Kit Includes:
• 14 x 6-way junction boxes
• 4 x 24” straight truss lengths
• 4 x 30” straight truss lengths
• 7 x 36” straight truss lengths
• 7 x 46” straight truss lengths
• 16 x 45º curved truss lengths
• full set of quicklock connectors
• 4 x junction base
• 2 x oval counters with plex
• 12 x 45º internal shelves
• 6 x 50 watt spotlights
• 1 x OCF molded case
• 2 x OCF2 molded cases

Dimensions
HARDWARE: Fits in a 10’ x 20’ space

GRAPHIC Total finished size:
Panels AI1, AI2, AI4 & AI5: 43”w x 83.75”h
Panel AI3: 84.25”w x 89”h
Panels AI6 & AI7: 82.50”w x 6”h
Panels AI8 & AI9: 25.75”w x 36.13”h

*All dimensions available in millimeters
Please be sure to include a 2” bleed around perimeter.
Refer to related graphic template for specific information on sizes and bleeds. Dye-sublimated graphic require different bleed than UV.

Additional Information
- Graphic materials: Dye sublimated panels
- Lumina 1, 50 watt spotlight
- Tabletops (each): max weight= 25 lbs / 11.34 kgs
- Counter: max weight = 35 lbs / 15.88 kgs
- Shelves (each): max weight = 25 lbs / 11.34 kgs
